KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C
KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C

KZ25/KZ35 Electronic Load Battery Testser QC2.0/3.0 AFC FCP Triggers Constant Current Voltage Capacity Meter Voltmeter, USB Type-C

 (0 reviews)
Blank
|
SKU4C0582S
$18.92 $0.00( / )
Tax included.Estoque no Brasil. Sem Risco de Taxa. Shipping calculated at checkout.
Features： 1. Good heat dissipation, using intelligent temperature control fan plus full aluminum heat sink2. USB intelligent electronic load, can be used as an ordinary electronic load, can also be used as a USB electronic load, can induce support QC2.0/Q C3.0/AFC/FCP fast charging protocol, trigger output 5V/9V/12V/20V and other voltages3....
  • 4A/25W
  • 5A/35W
  • CN
Comprar agora
Ask about this product

Features：

1. Good heat dissipation, using intelligent temperature control fan plus full aluminum heat sink
2. USB intelligent electronic load, can be used as an ordinary electronic load, can also be used as a USB electronic load, can induce support QC2.0/Q C3.0/AFC/FCP fast charging protocol, trigger output 5V/9V/12V/20V and other voltages
3. LCD display, friendly human-machine interface and excellent performance indicators to meet the diversified testing needs
4. Products with reverse connection protection, reverse connection does not burn
5. A variety of functions suitable for a variety of test environments, whether digital players for performance testing, or factory product aging, a machine to deal with!

Specfication:

Rated operating voltage: DC4.0-25.0V (with anti-reverse connection protection, reverse connection does not burn)
Maximum discharge power: KZ25: 25W/KZ35: 35w

Rated working current:
KZ25: 0.03-4.00A (0.22A start adjustment when fan starts)
KZ35: 0.03-5.00A (0.22A at the start of the fan)

Maximum fan speed:
KZ25: Oil bearing fan 5800±10%RPM
KZ35: hydraulic bearing fan 8000±10%RPM

Fast charging trigger mode: QC2.0 5V, 9V, 12V, 20V, QC3.0, AFC9V , FCP
Constant current accuracy: ± (1% + 3 words)
Voltage accuracy: ± (0.5% + 3 words)
Heat dissipation mode: intelligent temperature-controlled fan + all-aluminum heat sink
Operating ambient temperature: -20℃-40℃
Expansion interface: Micro USB interface, Type-C interface
Overvoltage protection (OVP): default 25.2V (can be set by yourself)

Over-current protection (OCP):
KZ25: default 4.10A (can be set by yourself)
KZ35: default 5.10A (can be set by yourself)

Over power protection (OPP):
KZ25: default 25.5W (can be set by yourself)
KZ35: default 35.5W (can be set by yourself)

Undervoltage protection (LVP): default 4.0V (can be set by yourself)
Over temperature protection (OTP): default around 80°C (can not be set)
Application suggestion: KZ35 is recommended for factory batch aging

Package list

Electronic load*1（25W/35W optional）

Fornecedor:

Blank

Model:

4A/25W, 5A/35W
Ship From:

CN
SKU:

SKU4C0582S
